The power supply (PSU) is an important part of a computer system that converts electrical current from a source into a current that hardware can use. Without a good PSU, all computer components, from the processor to the graphics card, will not function optimally. Therefore, choosing the right PSU is very important so all components have enough stable power.
The importance of PSUs in computer systems lies not only in the provision of power but also in the overall performance of the system. Every device in a computer, such as motherboards, hard drives, and graphics cards, has certain power needs that must be met. If the PSU is not able to provide enough power, it can cause various problems, such as degraded system performance, damage to hardware, and system instability that can result in crashes or freezes.
Other Interesting Articles
Calculating Power Requirements
One of the important steps in choosing a power supply is to make sure all of your computer’s components are getting enough power. Here is a guide to calculating power requirements.
Device Power Consumption Table
Here are the estimated power consumption of some of the main components of the computer:
| Component | Power Consumption (Watts) |
| Processor | 10–100 W |
| Graphics card (GPU) | 20–300 W |
| Hard drive (HDD/SSD) | 3–15 W |
| CD/DVD drive | 10–25 W |
| Motherboard | 5–50 W |
| RAM | 2–5 W per module |
| CPU Cooler | 5–10 W |
How to Calculate Total Power Required
1. Identify the Components Used
Take note of all the devices on your computer, such as CPU, GPU, RAM, hard drive, and other enhancements.
2. Calculate the Power Consumption of Each Component
Use the power consumption table to estimate the power needs of each component.
3. Total Power Requirements
Add up all the power requirements of the components. Examples:
- Intel Core i5 processor (65 W)
- NVIDIA GeForce GTX 1660 Graphics Card (120 W)
- 1 Hard Drive (10 W)
- 1 SSD (5 W)
- Motherboard (30 W)
- 2 module RAM (2 × 5 W = 10 W)
Total power requirement = 65 + 120 + 10 + 5 + 30 + 10 = 240 W
4. Provide Power Backup
It is recommended to add about 20–30% of the total power as a backup to maintain stability, especially when components are operating at maximum load.
Example:
- Total power requirement = 240 W
- Power reserve = 30% × 240 = 72 W
- Total minimum power power supply = 240 + 72 = 312 W.
Online Tools for Calculating Power
Several online tools can help you calculate your power needs more easily and accurately. Some of them are:
- OuterVision Power Supply Calculator: This tool allows you to insert all components and provide an estimate of the required power.
- Cooler Master Power Supply Calculator: Provides a simple interface for entering hardware specifications and calculating power requirements.
- Newegg Power Supply Calculator: Allows the user to select a component from the list and calculate the total wattage required.
Choosing the Right Power Supply
Choosing the right power supply is essential to ensure the performance and stability of your computer system. Here are some things to keep in mind:
1. Suitable Wattage Capacity
The wattage capacity of the power supply must match the total power requirements of all computer components. Be sure to calculate the total wattage required, including the processor, graphics card, and other devices. As a general guide:
- Use the power requirement calculation (as described earlier) and add 20–30% as a backup.
- Avoid using a power supply with too small a capacity, as it may cause the system to be unstable, or too large, as it will waste electricity.
- Standard computers typically require a power supply with capacities ranging from 400W to 600W.
- A more powerful gaming computer or workstation may require a power supply with a capacity of more than 600W.
